Öztiryakiler Industrial Type Dishwasher, Oby 500 Rinse Aid, Detergent, Drain Pump

Öztiryakiler Industrial Type Dishwasher, OBY 500 - Features with Rinse Aid, Detergent, Drain Pump

• Stainless steel body, boiler, and hygienic washing tank

• Easy cleaning with rounded monoblock tank structure

• Effective washing per minute: Capacity of 35 baskets (560 plates) per hour

• Basket size: 50 × 50 cm

• Low water consumption: Only 2.8 L per wash

• User-friendly digital panel and fault tracking on the screen

• 5 different pre-selectable washing programs

• Thermostat-controlled washing and rinsing temperatures

• Saves on energy, detergent, and water usage

• Boilers and tanks can be filled and heated with one button

• AISI 304 quality stainless steel washing arms and PP supported structure

• Height-adjustable feet

• High durability against water with IPX5 protection class

• Safe use with valve system preventing water backflow

• Includes 1 flat glass basket and 1 round cutlery basket

Technical Specifications

• Model: OBY 500

• Type: Electric

• Product Code: Not Specified

• Capacity: 560 Plates/hour

• Voltage: 230V NPE

• Frequency: 50 Hz

• Electric Power: 5.5 kW

• Boiler Heater Power: 5 kW

• Tank Heater Power: 2 kW

• Washing Pump Power: 0.66 kW

• Washing Pump Flow Rate: 356 L/min

• Rinsing Pump Flow Rate: 18 L/min

• Tank Capacity: 30 L

• Boiler Capacity: 6 L

• Washing Water Temperature: 55–60 °C

• Rinsing Water Temperature: 80–85 °C

• Maximum Noise: 75 dBA

Connection Information

• Cold Water Pressure: 2–4 bar

• Hot Water Pressure: 2–4 bar

• Cold/Hot Water Hardness: 0–10 French Hardness

• Drainage Inlet Diameter: 3/4''

Dimensions and Weight

• Width x Depth x Height: 595 × 655 × 830 mm

• Net Weight: 65 kg (±5 kg)

• Gross Weight: 70 kg (±5 kg)

Brand and Origin

• Brand: Öztiryakiler

• Origin: Turkey
