Out Of Stock
Notify me when its in stock| PRODUCT CODE | 076R.00100.BD |
| DESCRIPTION | *Body, boiler, and washing tank made of stainless steel *Seamless and rounded corner hygienic washing tank *100 baskets per hour washing capacity (Basket dimensions 50cmx50cm) *Effective drying with high-power fan *3 liters of water consumption per washing cycle *Automatic and user-friendly control panel *Continuous washing with drying thanks to the conveyor system *Energy, detergent, and water usage savings *Washing arms made of stainless steel *Height optimization with adjustable legs *Easy start; fill and heat water in boiler and washing tanks with a single button *Electrical components and wiring systems comply with international standards and safety *Entire body is insulated and protected against water with IPX5 protection standard *Rinse and wash temperatures are thermostat-controlled for effective washing *Valve system preventing water in the machine from returning to the plumbing *Washing water temperature 55-60°C (provided the supply water is at least 2 bar and 50°C) *Rinse water temperature 80-85°C (provided the supply water is at least 2 bar and 50°C) *Right entry table |
| TYPE | Electric |
| WIDTH (mm) | 1750 |
| LENGTH (mm) | 850 |
| HEIGHT (mm) | 1500 |
| NET WEIGHT (Kg) | 220 |
| GROSS WEIGHT (Kg) | 220 |
| VOLUME (m3) | 2.1 |
| CAPACITY | 1650 Plates/Hour |
| ELECTRIC POWER | 38 |
| VOLTAGE | 400V - 3 NPE |
| FREQUENCY | 50 |
| HOT WATER PRESSURE | 2-4 bar |
| HOT WATER HARDNESS | 0-10 French Hardness |
| COLD WATER INLET DIAMETER | 3/4'' |
| COLD WATER PRESSURE | 2-4 bar |
| COLD WATER HARDNESS | 0-10 French Hardness |
| DRAINAGE INLET DIAMETER | Ø 50 |
| TANK VOLUME | 90 |
| BOILER VOLUME | 18 |
| WASH PUMP FLOW RATE | 659 |
| RINSE PUMP FLOW RATE | 18 |
| BOILER HEATER POWER | 27 |
| TANK HEATER POWER | 9 |
| WASH PUMP POWER | 1.5 |
| RINSE PUMP POWER | 0.37 |
| WASHING WATER TEMPERATURE | 55 - 60 |
| RINSING WATER TEMPERATURE | 80 - 85 |
| DRYING FAN POWER | - |
| MAXIMUM NOISE | 80 |
| PROTECTION CLASS | IPX5 |
| PRODUCT ORIGIN | Turkey |
| BRAND | Öztiryakiler |
